KGPS-776
The KGPS-776 is a Dual mode GPS Mobile Antenna for the 370-512 MHz Band, 1575 Mhz in GPS. This antenna has been designed for use on radio networks with GPS control on the mobile units operating in the entire UHF band.
Register to see price
Part Number: OPN2453X078
Tags: K GPS/NMO Mobile Antenna
When ordering, please, specify: Exact Tx Rx frequencies. Connector type ( BNC, PL.TNC,N,FME,SMA). Connector GPS ( SMA, FME,SMB....). With or W/O Spring (S4).
Description
Technical Specs
Patterns & Curves
The KGPS-776 is a Dual mode GPS Mobile Antenna for the 370-512 MHz Band, 1575 Mhz in GPS. This antenna has been designed for use on radio networks with GPS control on the mobile units operating in the entire UHF band.
Very robust and easy to install, it has become the favourite of most Tetra public operators in Europe.
| ELECTRICAL SPECS | |
|---|---|
| Frequency Range | 380 – 470 MHz |
| Input Power | 100 W |
| SWR | < 1.5:1 |
| Impedance | 50 Ω |
| Polarization | Vertical |
| Gain | 0 dB without ground plane |
| GPS Gain | 27 dB active |
| Supply voltage GPS | From 2.7 to 5V dc |
| Noise Figure | 1.7 to 2.1 dB |
| Cable RF | RG 58/U |
| Cable GPS | RG 174/U |
| MECHANICAL SPECS | |
|---|---|
| Length | 20 cm max. |
| Weight | 0.4 Kg |
